DC Electronic Loads

els 250 ELA Series 250W to 500W

Load voltages from 1 to 110Vdc, Load currents from 0 to 199A
Static and dynamic applications, Constant current mode, Full remote control and monitoring.
Optional IEEE 488.2 interface card with LabVIEW driver, Optional resistance mode (similar to constant conductance)

el 3000w white EL Series 500W to 20kW

Load voltages from 0.1 to 800Vdc, Load currents from 0 to 1000A
Static and dynamic applications, Constant current, Constant power, Constant voltage, and Constant conductance modes, Full remote control and monitoring.
Optional IEEE 488.2 interface card with LabVIEW driver.

DCL Front View DCL Series 3kW Modular

Load voltages from 0.3 to 800Vdc, Load currents from 0.01A to 350A. Microcontroller based and digitally cotrolled from a tablet or PC.Static and dynamic applications, Constant current, Constant power, Constant voltage, and Constant conductance modes, Full remote control and monitoring.
Optional IEEE 488.2 interface card with LabVIEW driver.

ELS Series 20kW to 100kW (Systems)

Load voltages from 0.1 to 800Vdc, Load currents from 0 to 2000A
Static and dynamic applications, Constant current, Constant power, Constant voltage, and Constant conductance modes, Full remote control and monitoring.
Optional IEEE 488.2 interface card with LabVIEW driver.

New PRL Power Recycling Load (Green Load)

This unit, which is ideal for burn in applications, feeds back the DC Energy into the AC mains to reduce energy consumption and cooling costs. Load voltages from 0.1 to 60Vdc, Load current from 0 to 80A. Static and dynamic applications, Constant current, Constant power, Constant resistance modes, Full remote control and monitoring, Integrated IEEE 488.2 interface card.

Product Summary

Zentro-Elektrik Electronic DC Loads range from bench top units of 500W to 100kW rack mounted systems, with four main operating modes

Constant Current | Constant Power | Constant Voltage | Constant Conductance

For more information on the use of these operating modes please consult our explanation of operating modes document.

An overview of the ranges is shown above, but for more detailed information please select the relevant link, or fill out and submit the form on the left of this page

If you would like to discuss your application in more detail please call us on +44 (0) 2476 214799 or fill out and submit the form on the left of this page.
